MRCOOL 80% AFUE 4 Ton 90,000 BTU 1,600 CFM Upflow/Horizontal 5-Speed Gas Furnace, MGM80SE090B4A
MRCOOL 80% AFUE 4 Ton 90,000 BTU 1,600 CFM Upflow/Horizontal 5-Speed Gas Furnace, MGM80SE090B4A
Stay Warm and Save with the MRCOOL 80% AFUE Gas Furnace
When winter's chill takes hold, nothing compares to the warmth and safety provided by a powerful, reliable gas furnace. Among the best on the market is the MRCOOL single-stage, 80% AFUE gas furnace. Designed for upflow or horizontal installation, this system is built to deliver decades of dependable heating, all while keeping your energy bills affordable. With its 80% AFUE rating, this furnace ensures that 80% of every dollar spent on heating fuel is converted into real, effective heat for your home.
Key Features:
- High Efficiency: Delivers an 80% AFUE rating, ensuring you get maximum value from your heating fuel.
- Flexible Installation: Can be easily installed in upflow or horizontal configurations, with a removable floor base for bottom return air.
- Easy Maintenance: The slide-out blower design is easily removable, simplifying routine maintenance.
- Versatile Utility Connections: Offers left or right utility connections to suit various installation setups.
- Simple Conversion: Zero step horizontal conversion streamlines the installation process.
- Smooth Ignition: Aluminized steel inshot burners ensure reliable, smooth ignition every time.
- Durable Construction: Features an aluminized steel tapered crimped non-welded clam shell heat exchanger for long-lasting durability.
- Quiet & Efficient Operation: Equipped with a multi-speed, high-efficiency (constant torque) blower motor for consistent and quiet airflow.
- Compact Design: With a compact 33" height, it fits easily into a variety of spaces.
- Venting Flexibility: The rotatable draft inducer provides flexibility for venting configurations.
- Certified Quality: AHRI Certified, meeting high industry standards for performance and efficiency.
- Warranty: Comes with a registered 10-year parts warranty, ensuring peace of mind and long-term reliability.
Choose the MRCOOL 80% AFUE Gas Furnace for a reliable, efficient, and cost-effective heating solution that keeps your home warm and cozy throughout the winter.
PRODUCT SPECIFICATIONS:
| Product Dimensions | 17.5'W x 28 3/8'D x 33'H |
| Product Weight | 142 lbs |
| Unit Type | Gas Furnace |
| AFUE | 80% |
| CFM | 1615 |
| Tonnage | 4 |
| Heating Capacity | 88,000 BTU |
| Fuel Type | Natural Gas |
| BTU Input | 88,000 |
| BTU Output | 70,400 |
| Voltage |
Requires a minimum of 120V/60HZ/15A |
| Phase | 1 |
| Cycle | 60 |
| Stage | Single |
| Max Fuse Breaker | 15 |
| Min Circuit Ampacity | 8.4 |
| Color | Gray |
| Full Load | 8.4 |
| Number of Burners | 8 |
| Gas Connection Size | 0.5 |
| Blower Motor Type | ECM |
| Blower Motor HP | 3/4 |
| Blower Motor Speeds | 5 Speed |
| Blower Motor RPM | 955-1615 |
| Heat Exchanger Type | Aluminized steel |
| Ignition Type | Silicon Nitride Ignitor |
| Vent Connector | 4 inch |
| LP Kit Available | Yes |
| Certifications | CSA AHRI |
| Warranty |
Registered 10 Year Parts Warranty |
| Restricted States | Yes (California) |
Original: $1,401.00
-65%$1,401.00
$490.35More Images
